Features
3 Phase Machine
- ISO 9002 Certified
- Heavy welded all steel construction for maximum rigidity
- Quiet electrical motor
- 1/2 in roll opening
- Planetary reduction gear and pump
- All three rolls are made of high grade alloy steel, hardened up to 40 HRC
- All rolls run ford and reverse
- Safety type removable foot pedal
- Overload protection and disconnect switch
- One year warranty on parts
Standard Equipment
- Electrical cabinet
- Removable safety foot pedal
| Model | PSR-5016 |
| Rolling capacity: mild steel, min. thickness capacity |
50 in x 16 Ga. 50 in x 22 Ga. |
| Rolls size, length x diameter Min. roll bending diameter capacity |
50 in x 3 in 3-1/4 in |
| Rolls speed | 201 in / min |
| Rolls opening | 1/2 in |
| (3) grooves sizes | 5/16 in, 3/8 in , 1/2 in |
| PSR-5016 | 1 HP,220V/440V, 3 ph |
| Net weight | 828 LBS |
| Machine dimensions, LxWxH | 68x28x47 in |
- Free (3) wire grooves on the rollers
1 Year Parts Only Warranty
